TM FPV VTX
2.5W 5.8GHz TM Analog VTX 2.5W-5.8G VTX-FP FPV Video Transmitter
| Product Model | 2.5W-5.8G VTX-FP |
|---|---|
| Operating Voltage | 7–36V |
| Frequency Range | 4900~6100MHz |
| Channel Quantity | 88CH |
| Power Levels | 25mW, 0.5W, 1W, 1.5W, 2.5W |
Request Quote
Quotation within 24 hours · MOQ from 1 unit · OEM / ODM welcome
- OEM / ODM customization supported
- Prototype in 7–15 days
- 12-month warranty, 24h technical support
Product Details
Skyvolt 5.8GHz / 2.5W TM Analog VTX, Model: 2.5W-5.8G VTX-FPThis high-power analog FPV video transmitter is designed for long-range FPV drone flight, featuring multi-level adjustable transmit power and wide voltage input.
Features:
- Wide voltage input 7~36V, compatible with most FPV drone battery setups
- 88 channels, frequency range 4900~6100MHz
- 5 power output options, switchable via IRC Tramp
- Support OSD parameter adjustment, easy to configure on your goggles
- MMCX antenna connector
- Compact size & lightweight, only 13.7g without antenna
| items | description |
|---|---|
| Control Protoco | IRC Tramp, OSD parameter adjustment supported |
| Modulation Type | FM Frequency Modulation |
| Channel Bandwidth | 2MHz |
| Antenna Connector | MMCX |
| Video Format | NTSC/PAL |
| Output Power | 34dBm±1dBm (MAX) |
| Dimensions | 36mm*35mm*8mm |
| Weight | 13.7g (Antenna excluded) |
